SDVoE Ultra-Compact 4K HDMI 2.0 over Fiber AVoIP Transmitter, extension up to 984ft (300m)

VLIP-SDFR-TX

Data Sheet

User Manual

Product Inquiry Form

Product Description

VLIP-SDFR-TX – Ultra-Compact 4K SDVoE AVoIP Transmitter is the industry’s most compact SDVoE-based HDMI 2.0 extender. When paired with the VLIP-SDFR-RX ultra-small receiver, it delivers an ultra-compact, zero-latency SDVoE AV-over-IP distribution solution with extension of up to 984ft (300m).

Engineered for high-performance 4K environments, these ultra-compact devices provide lossless 4K/60Hz video with near-zero compression and zero-frame latency—ideal for applications where precision and speed are critical.

With dimensions of just 87 mm x 64 mm x 22 mm, the extenders integrate seamlessly into space-constrained installations such as medical facilities, simulation systems, and command centers.

Supporting both point-to-point and asymmetrical matrix configurations via a 10G Ethernet switch, the system enables advanced routing scenarios with SDVoE controller-based management. Compatibility with Semtech BlueRiver AV Manager ensures centralized, scalable, and intelligent network control.

Works with VLIP-SDFR-RX - Ultra-Compact 4K HDMI 2.0 SDVoE AVoIP Receiver

Featured Highlights

Compact size and economical design
HDMI 2.0 and HDCP 2.2 compliant
Lossless distribution of most timing formats
Light compression with the raw data rate exceeding 10Gb Ethernet bandwidth
Supports input and output resolutions up to 4096x2160@60Hz 8-bit 4:4:4, 4096x2160@60Hz 10-bit 4:4:4 and 4096x2160@60Hz12-bit 4:2:0 HDR
Supports point-to-point transmission of 4K signal at the distance up to 300m
Supports point-to-multipoint, multipoint-to-multipoint transmission via 10GbE switch at the distance of up to 300m (between a device and the switch)
Zero-frame latency
Required bandwidth: 6~8 Gbps for 4K, 3.2 Gbps for 1080P
Compatible with Semtech BlueRiver AV Manager

Specifications


     VIDEO

     Input Connectors
     1 x HDMI

     Supported Input
     640x4808, 800x6008, 1024x7688, 1280x10248, 1360x7688 , 1440x9008,

 1440x10508, 1600x12008 , 720x4807(480i59),
720x4807(480p59),

 720x5766(576i50), 720x5766(576p50), 1280x7205(720p50), 1280x7207(720p59),

  1280x7208(720p60), 1920x10806(1080i50), 1920x10807(1080i59), 1920x10808(1080i60),

  1920x10801(1080p23), 1920x10802(1080p24), 1920x10803(1080p25), 1920x10804(1080p29),

  1920x10806(1080p30), 1920x10806(1080p50), 1920x10807(1080p59), 1920x10808(1080p60),

  3840x21601(2160p23), 3840x21602(2160p24), 3840x21603(2160p25), 3840x21604(2160p29),

  3840x21605(2160p30), 3840x21605(2160p60), 4096x21605, 4096x21608

 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at
30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz, 9 = 75 Hz;

     Output Connectors
     1 x SFP+, 10GBase-SR

     Supported Output
     640x4808, 800x6008, 1024x7688, 1280x10248, 1360x7688 , 1440x9008,

 1440x10508, 1600x12008 , 720x4807(480i59),
720x4807(480p59),

 720x5766(576i50), 720x5766(576p50), 1280x7205(720p50), 1280x7207(720p59),

  1280x7208(720p60), 1920x10806(1080i50), 1920x10807(1080i59), 1920x10808(1080i60),

  1920x10801(1080p23), 1920x10802(1080p24), 1920x10803(1080p25), 1920x10804(1080p29),

  1920x10806(1080p30), 1920x10806(1080p50), 1920x10807(1080p59), 1920x10808(1080p60),

  3840x21601(2160p23), 3840x21602(2160p24), 3840x21603(2160p25), 3840x21604(2160p29),

  3840x21605(2160p30), 3840x21605(2160p60), 4096x21605, 4096x21608

 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at

     AUDIO

    Input Connectors
     1 x HDMI

    Supported Input
     LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz

Dolby True HD, up to 7.1,192kHz

DTS-HD Master, up to 7.1,192kHz

Dolby Digital AC-3 (DVD format)

DTS version 1 (DVD format)

    Output Connectors
     1 x SFP+, 10GBase-SR

    Support Output
     LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz

Dolby True HD, up to 7.1,192kHz

DTS-HD Master, up to 7.1,192kHz

Dolby Digital AC-3 (DVD format)

DTS version 1 (DVD format)

     Control

    Control Connectors
    1 x SFP+, 10GBase-SR, 10GbE

    Control Method
     Ethernet:

  PC software: for configuring, controlling and upgrading

 Web browser: for controlling

 API set: for integrating with the 3rd party control system

     Mechanical

     Operating Temperature
     0 to + 40°C (32 to + 104 °F), 10% to 90%, non-condensing

     Storage Temperature
     -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing

     Humidity
     10% to 90%, non-condensing

     Product Weight
     0.35lb (0.16kg)

     Power Supply
     5V 2A DC

     Power Consumption
     4.5W

     Transport Distance
     300m with OM-3 multi-mode optical fiber

     Product Dimension
     87mm x 64mm x 22mm (L x W x H)

     ESD Protection
     Human-body Model: ±8kV(Air-gap discharge)/±4kV(Contact
discharge)
