AV over IP Controller for JPEG 2000
VLIP-JP1G-CTRL
Data Sheet
User Manual
Product Description
This Video over IP Controller controls and manages JPEG2000 IP products. It supports dual 100M network ports, which can realize dual-network isolation of the Control network and Multicast video distribution network. Built-in Web GUI, TCP, and RS-232 control are supported. It supports POE function and wide band 12V IR signal receiving. This IP Controller has the flexibility to be widely applied to the growing need for IP products in today’s digital world, commonly used in more and more different scenarios.
Product Inquiry Form
Featured Highlights
Easy to create projects and control the system
IP Configurations Flexibility - supports three types: Auto, DHCP, and Manual
Security compatibility - HTTPS, SSH, SFTP
Built-in web GUI control interface. Simple Drag & Drop operations
Toggle on/off - User Image preview module
Supports video, audio, RS-232, IR, and KVM control. Access to management of the distributed system
Isolate controls and multicast networks with dual network ports (VIDEO LAN port supports POE function)
Supports third-party central control with LAN/RS-232 port control
Supports IR signal receiving (3.5mm audio jack, 12V level)
4 channel GPIO control ports (5V/12V optional level)
Multiple circuits protection, plus lightning protection, and ESD design
Reliable system design, ensuring 24/7 usage for vital work
Specifications
| Technical | |
|---|---|
| Network Bandwidth | 100M |
| Transmission Distance | 100m CAT 5E/6/6A/7 |
| Control Ports | 2 x 100M LAN [RJ45 connector] [VIDEO LAN support POE] 1 x IR IN [3.5mm audio jack, 12V level] 1 x DIGITAL I/O [6-pin 3.81mm phoenix connector] 1 x RS-232 [3-pin 3.81mm phoenix connector] |
| Dimensions | 204mm(W)×98mm(D)×21mm(H) |
| Housing | Metal Enclosure |
| Color | Black |
| Weight | 509g |
| Power Supply | 12V/1A |
| Power Consumption | 4.5W |
| Operating Temperature | 0°C ~ 40°C / 32°F ~ 104°F |
| Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F |
| Relative Humidity | 20~90% RH (No condensation) |
